• Check whether the moving parts function faultless-
ly and do not jam or whether parts are damaged.
All parts must be correctly mounted and all condi-
tions must be fulfilled to ensure fault-free operation
of the power tool.
• In case of previously machined wood, be aware of
any foreign bodies, such as nails or screws, etc.
• Follow the running direction of the tool attachment.
10.1
Switching the product on/off
(fig. 1, 12)
Make sure that both safety switches (11a) engage
properly on the housing doors (11).
Switching on
1. Insert the mains plug into a properly fused mains
socket.
2. Push the ON/OFF switch (12), which is marked "I",
to switch the product on.
Switching off
1. Push the ON/OFF switch (12), which is marked "0",
to switch the product off.
2. Pull the mains plug out of the socket when the
product is not in use.
10.2
Parallel stop (20) (Fig. 13)
Note:
The parallel stop can be fitted to the right of the band
saw blade.
1. Push the clamping bar (20a) of the parallel stop (20)
up.
2. First place the parallel stop (20) on the rear of the
saw table (7) and then push the parallel stop (20)
down.
3. Move the parallel stop (20) and adjust it to the de-
sired dimension.
4. Push the clamping bar (20a) down to fix the parallel
stop (20) in place.
In order to increase the clamping force of the
clamping bar (20a), rotate it clockwise until the par-
allel stop (20) is sufficiently fixed in place.
5. Make sure that the parallel stop (20) always runs
parallel to the band saw blade (17).
10.3
Mitre gauge (19) (Fig. 1, 14)
1. Insert the mitre gauge (19) into the groove of the
saw table (7).
2. Loosen the knurled nut (19a).
3. Turn the mitre gauge (19) until the desired angle
has been set.
The arrow on the mitre gauge (19) indicates the set
angle.
4. Retighten the knurled nut (19a).
12
|
GB / IE / NI / CY / MT
10.4
Angled cuts (Figs. 1, 14, 15)
In order to execute angled cuts parallel to the band
saw blade (17), it is possible to tilt the saw table (7)
from 0° to 45°.
1. Undo the wing nut (22) and locking handle (23).
2. Tilt saw table (7) forwards, until the desired angle is
set on the degree scale (15).
3. Tighten the wing nut (22) and the locking handle
(23).
ATTENTION
With a tilted saw table, the parallel stop must always
be fitted to the right of the band saw blade. This pre-
vents the workpiece from slipping.
11 Working instructions
The following safe working methods are considered to
contribute to safety but may not be appropriate, fully or
extensively applicable for every use. They cannot cover
all possible hazardous conditions and must be inter-
preted carefully.
• Risk to health from wood dust or wood chippings.
It is essential that personal protective equipment,
such as eye protection, is worn. Use a chip ex-
traction system!
• If the product is not in operation, e.g. work is com-
plete, you should slacken the band saw blade. At-
tach a corresponding note to the product for the
next user about the tensioning of the band saw
blade.
• Store unused band saw blades together and safely
in a dry place. Check for faults, such as teeth or
cracks, before use. Do not use defective band saw
blades!
WARNING
Tool attachments may be sharp and become hot
during use. Always wear protective gloves when han-
dling the tool attachments.
• Check the covers and protective devices for dam-
age and correct seating. Replace them if neces-
sary.
• Wear hearing protection and safety goggles during
the entire operating period.
• Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away
from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
• Always position the band saw blade guide as close
as possible to the workpiece when working.
• Only work in daylight or with good, artificial lighting.
