Functional force monitoring check
Upon completion of the force measurement process, carry out a
functional check of the force monitoring function. Install the test
weight on the door again for this purpose. The drive must switch
off!
Force monitoring has not tripped during the
NOTICE
functional check
If the force monitoring function has not tripped,
the settings in menu item 48 must be checked.
The force measurement process must be re-
peated.
Duty cycle (menu item 49)
The duty cycle set prevents the drive motor from being over-
heated and avoids damage.
Motor 5.24 with a plastic gearbox
NOTICE
When motor 5.24 with a plastic gearbox is used,
the duty cycle must be set to the value 1 (3~) or
2 (WS, 1~).
Menu 6 Radio settings
Programming the hand-held radio transmitter
Please observe that every hand-held transmitter must be pro-
grammed individually.
You are provided with the possibility of programming 20 KeeLoq
radio codes
The following encryption types can be programmed: KeeLoq,
12 Bit Multibit. The first code programmed determines the encryp-
tion type.
Start pulse (menu item 60)
1.
Select "Program hand-held transmitter start button" in menu
item 60.
2.
Actuate the button of the hand-held transmitter for opening
the door.
ð
When the code has been programmed, the dot display
on the LED display blinks 5 times.
3.
Go to Exit to complete the setting process.
Light function (menu item 62)
Select menu item  62 and actuate the light function button of the
hand-held transmitter. When the code has been programmed, the
dot display on the display blinks 5 times.
Deleting radio codes (menu item 63)
To delete all codes programmed, proceed as follows:
1.
Select menu item 63.
2.
Press and hold the
When all codes have been deleted, the dot display on
the display blinks 5 times.
Test run
When programming has been completed, carry out a test run by
executing all operating functions. When all operating functions
have been executed correctly, the connected door system is
ready for operation.
 button for 5 seconds.
6

Program overview

Menu 3 Basic settings
Menu
Entry
Selection
item
30
Door setting of upper end position
Reversal of the direction (press for 5 s)
31
Door setting of lower end position
33
Fine correction of upper end position
50
Factory settings
50 - 0
0...80 mm lower
50 - 99 0...80 mm higher
34
Fine correction of lower end position
50
Factory settings
50 - 0
0...80 mm lower
50 - 99 0...80 mm higher
35
Selection of closing edge safety device
Measurement display (press 5 seconds)
0
Optical closing edge safety device OSE
1
Electrical safety edge 8K2 (default setting)
2
Pressure wave switch with testing
36
Selection of photoelectric sensor
0
Without photoelectric sensor (default setting)
1
2-wire photoelectric sensor LS2
2
4-wire photoelectric sensor LS5 photoelectric
reflection sensor
3
Photoelectric sensor LS2, mounted in frame
4
Photoelectric sensor LS5 photoelectric reflec-
tion sensor mounted in frame
5
4-wire photoelectric sensor with testing
6
4-wire photoelectric sensor in frame with test-
ing
37
Correction of pre-limit switch closing edge safety
25
Correction of pre-limit switch closing edge
safety (default setting)
25 - 0
0...50 mm lower
25 - 99 0...100 mm higher
- -
Exit menu
Menu 4 Further door settings
Menu
Entry
Selection
item
40
Selection of operating mode
0
Dead man OPEN / dead man CLOSE
1
Pulse OPEN / dead man CLOSE
2
Pulse OPEN / pulse CLOSE (default setting)
45
Status relay X3
0
Door close signal
1
Door open signal (default setting)
2
Warning during the process
3
5-minute light
4
Wipe pulse with hand transmitter
5
Wipe pulse
48
Opening force limitation
0
Off (default setting)
1-30
Entry of switch-off force
T75 DES
EN - 21
