EMERGENCY operation
Risk of being crushed or hit by the moving
WARNING
door in EMERGENCY operation
Persons can be struck when the door is closed
or collide with the door.
•
For EMERGENCY operation the door
needs to be checked and found to be in per-
fect condition.
•
While the "Dead man" operating mode is
active, a clear view to the door from the
place of operation must be ensured.
EMERGENCY operation permits the operation of the door with
defective or tripped safety devices.
EMERGENCY operation is activated after 5 seconds of perman-
ent actuation of "OPEN" or "CLOSE" whilst E06 or E07 is dis-
played and is indicated by an F30 message on the display.
Lighting (optional)
The control is provided with a relay output which is used to switch
the lighting (menu item 45).
External control devices / pulse generators (optional)
The door can be opened and closed by external control devices /
pulse generators.
Radio hand-held transmitter (optional)
Start button (functional process in pulse OPEN operating mode /
pulse CLOSE):
•
Initial pulse generation:
Drive starts and moves the door to the end position OPEN
or CLOSE that is set.
•
Pulse generation during the process:
Door stops.
•
New pulse:
Door continues moving in the opposite direction.
Light button:
•
The light function is a continuous light, which can be
switched irrespective of the "ON / OFF" door action.
Door action status display
Display State
Upper end position OPEN reached
Door end position has not been reached
Lower end position CLOSE reached
Representation of the door opening frequency
Representation of the door closing frequency
8
Troubleshooting
Error
State
E03
Door neither opens nor
closes. Wicket door open
E05
Door neither opens nor
closes
E06
Door reverses / does not
close
E07
Door reverses / does not
close
E08
Door neither opens nor
closes
E09
Door neither opens nor
closes
E10
Programming of
photoelectric sensor
position
E51
Door does not open
E52
Door neither opens nor
closes
E53
Door does not close
E54
Door does not open
E55
Door neither opens nor
closes
E56
Door does not close
E5E
Door only closes in dead
man mode
F2
No response
F3
F4
F5
No response
F06
No response
F10
Door stops after start
command
T75 DES
Diagnosed cause
Close wicket door.
Safety circuit at J3
interrupted. Check slack
rope switch.
Closing edge safety device
has tripped. Check closing
edge safety device. Check
cabling. With 8k2 closing
edge keep programming
button pressed on menu
item 35 for 5 sec.
Photoelectric sensor has
triggered. Check menu
item 36.
Thermal contact of drive has
tripped. Let drive cool down.
Emergency release of drive,
lock drive again.
No door end position
programmed.
Program door end position
under menu items 30 + 31.
Position of photoelectric
sensor in frame not
programmed. Open and
close door completely.
Adjust photoelectric sensor
Continuous start cover
button OPEN, button is
stuck, check.
Cover button STOP
pressed, button stuck, cable
not connected.
Continuous start cover
button CLOSE, button stuck,
check.
Continuous start J1.3 button
OPEN, button stuck, check.
External STOP button J1.2
pressed or bridge missing,
check cabling to external
command transmitter
Continuous start J1.4 button
CLOSE, button stuck,
check.
Service cycles elapsed.
Have service carried out.
Error occurred during self-
testing. Switch control on /
off.
Error occurred during self-
testing. Switch control on /
off.
Error occurred during self-
testing. Switch control on /
off.
Fault in the control
electronics. Switch control
on / off.
EN - 23
