8
Install the mirrored glass
9
Install the light shield
CAUTION: The magnet at the top will hold the glass
in place to facilitate installation. It is necessary to
install the bracket to ensure the glass does not fall.
1. Secure the suction cup to the reflective side of
the mirrored glass (black edge goes at the top).
2. Lift the mirrored glass and place it into the
bottom slot at an angle, then tilt the mirrored
glass into a vertical position.
3. Align the bracket to two screw holes and secure
with screws.
Align the holes of light shield and secure using two screws.
