Technical Specifications
Electrical Requirements
WARNING: Construction and wiring must comply with local building codes and other applicable regulations to
reduce the risk of fire, electric shock and injury to persons.
WARNING: To reduce the risk of fire, electric shock or injury to persons, always use a licensed electrician.
!
NOTE: A dedicated, properly fused 13 Amp circuit is required, rated for the appropriate voltage (230-240V). An
isolation switch should also be incorporated in cases where the product plug is inaccessible after installation.
Technical Information
Rating : 230-240V~50Hz
Heat Output
Nominal Heat Output
Minimum Heat Output
Maximum Continous Heat Output
Auxiliary Electricity Consumption
In Standby Mode
Product Dimensions
A
Model
A
ASP30-EU
777 mm
ASP36-EU
929 mm
ASP42-EU
1082 mm
6
230V
P
1.8
Nom
P
0.9
min
P
1.8
max,c
el
0.5
SB
155 mm
155 mm
B
87 mm
87 mm
B
C
711 mm
953 mm
864 mm
1105 mm
940 mm
1181 mm
240V
-
1.9
kW
-
0.9
kW
-
1.9
kW
-
0.5
W
445 mm
445 mm
C
Open-sided install
(kit sold separately)
268 mm
178 mm
131 mm
131 mm
38 mm
38 mm
