Operation
Standby
Flame Effect
Heat
Heat Disable
Flame Speed
Timer
Brightness
Flame Sound
Factory reset
20
Press
to turn on the unit or to put it in standby mode.
When the unit is turned back on, it will retain the previously used settings.
Press
to turn the flame theme and ember bed on or off. Press
through the different flame theme settings, indicated by LEDs on the remote control.
Theme 1-6: Various flame effects; embers and logs on.
Theme 7: Midnight mode - flames on; embers and logs off
Theme 8: Dusk mode - flames off; embers and logs on
Theme 9: Custom - set using the Flame Connect app.
Press
to turn the heat on or off. Press
indicated by LEDs on the remote control. The
heat is on.
Blue LED: Fan only
Green LED: Eco mode (18°C, low fan speed)
Level 1: 18°C
Level 2: 20°C
Level 3: 22°C
Level 4: 24°C
Level 5: 26°C
Red LED: Heat boost (max heat for 20 minutes before returning to level 5)
White LEDs 1 & 8: Custom schedule - set using the Flame Connect app.
The set temperature is only displayed on the Flame Connect app.
The fireplace can be operated in heat only mode by turning off the flame.
on the onboard controls for 10 seconds to disable or enable the
Press and hold
heat function.
When the heat is disabled and the
Press
to adjust the flame speed using
When this function is active, the fireplace will turn off after a set amount of time. The
timer can be set from 1 hour to 8 hours.
Press
to activate the timer. Press the
the timer off, press
twice.
While the timer is active, press
on the remote represents the number of hours remaining.
Press
to turn the overhead lights on or off. Press
the flame, logs, ember bed, and overhead lights.
Press
to turn the flame sound effect on or off. Press
More flame sounds are available through the Flame Connect App .
Press
,
,
,
,
,
to factory default. This action will also disconnect the unit from the Wi-Fi network and
the remote control will have to be resynchronized to the unit.
or
is pressed, the
or
or
to see the time remaining. The position of the lit LED
in sequence on the onboard controls to reset all the settings
or
to cycle through the heat settings,
will remain lit on the fireplace while the
icon will flash three times.
to cycle through the settings.
to cycle through the intervals. To turn
or
to adjust the brightness of
or
to adjust the volume.
to cycle
