Installation
12
Place the logs
Aspire 30
1
3
Aspire 36
1
3
2
Aspire 42
1
3
Recommended log layout
8
7
2
5
4
2
1. Connect the log to the connector with the
corresponding label number, and place it as shown
below.
NOTE:
Log #7 does not have a connector.
2. Place the large glass chunks to conceal the
connectors.
10
11
9
8
6
7
8
5
6
7
1. Place 7 .
2. Place 2 and 9 .
3. Place 1 and 11 . These go
up against the mirror, and
rest on top of 2 and 9 .
4. Place 3 , 8 , and 10 .
Aspire 42:
5. Place 4 .
Aspire 36 & Aspire 42:
6. Place 5 and 6 .
11
10
9
11
9
10
