WLAN indicator light
Lights up green: WLAN connected, server
access established
Flashes green: WLAN connected or not
connected to the server.
No green light: WLAN not connected.
LoRa indicator light
Lights up green: normal communication
between the robotic mower and RTK an-
tenna
Flashes green: Connection is being estab-
lished.
No green light: Communication disorder
Power indicator light
Lights up green: Power fault
Flashes green: Power connection estab-
lished
No green light: no power
Activating the lawnmower
1. Place the lawnmower on the charging station.
Note
Ensure that the battery contacts are connected correct-
ly.
When the lawnmower is correctly connected and
charging, the LED on the charging station flashes.
Illustration N
2. Press and hold the ON / OFF button for a few sec-
onds.
3. Enter the password and confirm.
Note
Confirm with "OK" after each digit entered.
The default password is "0000".
When entering the password, the START button can be
used as a plus button (+) and the HOME button as a mi-
nus button (-).
Connecting the lawnmower with the app
Before you download the app, make sure you have the
following:
● The device is on the charging station and is charg-
ing properly.
● The WLAN coverage is sufficient.
● The 2.4 GHz WLAN of the router is activated.
Download the KÄRCHER Outdoor Robots app from the
®
Apple App Store
or from the Google Play™ store.
20
● Google Play™ and Android™ are trademarks or
registered trademarks of Google Inc.
®
● Apple
and App Store
tered trademarks of Apple Inc.
The KÄRCHER Outdoor Robots app offers the following
main functions, among others:
● Connecting and activating and the lawnmower.
● Map creation
● Query the status and work progress of the lawn-
mower.
● Remote control: start, stop, return to charging sta-
tion
● Display and change the working settings of the
lawnmower (mowing plan, cutting height, map man-
agement).
● Display and change the safety/function settings of
the lawnmower (PIN, blade stop, etc.).
● Display or update the firmware version of the de-
vice, display the network connection status.
● Unlink, change or add devices.
● Call up help information and customer service sup-
port.
Connect the lawnmower with the KÄRCHER Out-
door Robots app:
1. Download the KÄRCHER Outdoor Robots app from
the Apple App Store or from the Google Play Store.
2. Open the KÄRCHER Outdoor Robots app.
3. Create an account and log in.
4. Switch on Bluetooth and WLAN on the smartphone.
5. Scan the SN code of the device to add the lawn-
mower.
6. Once the connection has been successfully com-
pleted, enter the default password 0000. The pass-
word can be changed in the app.
7. Follow the step-by-step instructions in the App.
Change password
1. Press and hold the START button and HOME button
for 3 seconds.
Illustration J
2. Enter the old password.
a Set digit by digit by pressing the START and
HOME buttons.
START button (+):
Illustration K
HOME button (-):
Illustration L
b Confirm each digit with OK.
Illustration M
3. Enter the new password and confirm with OK.
English
®
are trademarks or regis-
Operation
