ENGLISH
BEFORE MACHINE START-UP
Checklist
1.
Have a full knowledge of the machine operating controls and their functions.
2.
Insert the key (61) and start the machine (see the procedure in the following paragraph).
3.
Check the fuel reserve warning light (71). If it is on, refuel with petrol or replace the LPG tank (see previous paragraph).
4.
Check the horn with switch (67), the reverse gear buzzer with switch (68) and the working light switch (78, optional) for proper
operation.
5.
6.
Check the service brake pedal (6) for proper operation.
WARNING!
7.
Make sure that there are no open doors/hoods and that the machine is in normal operating conditions.
Cleaning planning
1.
Arrange long runs with a minimum of stopping or starting.
2.
Allow a small amount of broom path overlap to ensure complete coverage.
3.
Avoid making sharp turns, bumping or scraping the side of the machine.
Filling the DustGuard™ system water tank (optional)
1.
2.
STARTING AND STOPPING THE MACHINE
Starting the machine
1.
Sit on the driver's seat (3) and adjust it with the lever (4) to allow easy reach of all controls.
NOTE
The driver's seat (3) is equipped with a safety sensor, which allows the machine to be driven only when the operator is
on the driver's seat.
2.
Pull the engine choke lever (55).
NOTE
(For Petrol version). Do not use the choke lever if the engine is hot and if the air temperature exceeds 20 °C.
NOTE
(For LPG version). Always use the choke lever to approximately half stroke.
3.
Insert the ignition key (61) and turn it clockwise to "II". When the engine starts, release the key. Wait (a few seconds) for the
display (69) to turn on and sowing the working hours.
CAUTION!
When starting the engine do not press the drive pedal (5).
4.
After the ignition, let the engine run for a few seconds, then release the choke lever (55).
5.
Disengage the parking brake.
6.
Drive the machine to the working area, by keeping the hands on the steering wheel (1) and pressing the pedal (5).
7.
The forward/reverse direction is selected with the relevant switch (68) on the dashboard. When the reverse gear is selected,
the relevant buzzer turns on.
8.
Lower the main broom with the lever (63).
9.
Lower the side brooms with the lever (64).
NOTE
When the brooms are lowered, the brooms, the vacuum system and the dust guard system (optional - if turned on with
the switch (80)) automatically activates only when the machine is moving.
16
USER MANUAL
SW4000 - 1464815000
