7�6�3
History
Air leak history
– Thopaz + provides air leak history graphs and fluid history
graphs�
– For scrolling through the graphs press "Next"�
– To get back to your main display press "Home"�
– Three different air leak history graphs (72 h/Autoscale,
24 h/1000 ml/min, 24 h/100 ml/min) plus the catheter check
(see chapter 7�7 – Catheter check) are available�
– The air leak autoscale history graph adjusts the air leak scale
to the largest measured air leak from the last 72 h to
1000/2000/3000/4000/5000 ml/min�
Set and measured pressure
(depending on your settings)
Press [
] to get into the air
leak history�
Air leak scale (in ml/min)
Preparation for use/operating instructions
Pressure scale
Air leak
Current time
Current page
