7�7
Catheter check
Important: the catheter check works only with a patient
catheter (drain) in the interpleural space.
– The catheter check is only active if the air leak is 0 ml/min�
– Follow instructions on screen�
– A pressure difference from minimal 3 cmH
inspiration [
] and expiration [
leak of 0 ml/min� This pressure difference is an indication
for the respiration cycle of the patient and confirms that the
patient catheter (drain) is not clogged�
Press [
] to get into the air
leak history� Scroll to page 4/4
by pressing "Next" [
1
2
O between
2
] is displayed at an air
Patient catheter (drain)
open
Patient catheter (drain)
clogged?
This number shows the measured
maximal and minimal pressure of each
breathing cycle� This pressure is
indicated in the set pressure unit�
Preparation for use/operating instructions
]�
