Visible on display
Error
Problem
number
description
311
Selftest failed
313
Filter clogged
Thopaz +
315
overheated
407
Fluid alarm
Internal error
XXX
Safety related tip
The acoustic alarm "Leak in system – 301" is deactivated for approximately 6 minutes
after Thopaz + is switched on�
Safety related tip
Warning "canister full"/Alarm "filter clogged"�
The warning "canister full" is triggered when the canister filling level approximately reaches the
maximal scale line indicated on the respective canister label� Change the canister according the
instructions of use, chapter 8 – Replace canister� If secretions line the walls of the canister, the
warning "canister full" may be activated prematurely�
After muting the warning with the selection buttons, a symbol [
After 5 minutes the warning reappears acoustically�
An overfilling of the respective canister volume will trigger the alarm "filter clogged"� The alarm
is triggered due to the clogging of the hydrophilic filter upon contact with liquids or secretions�
Please refer to chapter "4 – Overview" for location of the hydrophilic, overflow protection/
bacteria filter in the canisters� Subsequent to a clogged filter and the alarm "filter clogged"
the vacuum applied to the patient is interrupted and cannot be regulated or maintained�
An additional accumulation of liquids, secretions and air is released through the pressure relieve
valve at the positive pressure of 0�2 - 0�5 kPa� This pressure release function is not a substitute for
a free overflow function� Therefore the canister must be replaced once full� Please refer to
chapter "4 – Overview" for location of the pressure relieve valve�
Change the canister according to the instructions for use, chapter "8 – Replace canister"�
44 |
Troubleshooting and alarms
Troubleshooting
instructions
Snap the canister out and
in again
1� Clamp tubing
2� Replace canister
3� Continue with "On"
4� Unclamp tubing
Replace Thopaz +
Patient is losing a large
amount of fluid
1� Switch Thopaz + off and on
again
2� Inform Medela Customer
Service
Remarks / Potential source of
error
Do not switch Thopaz + on if
the patient is already
connected�
Filter in canister clogged�
If error message repeats,
inform Medela Customer
Service�
] appears during operation�
Pressure
No
No
No
Yes
