Scope of delivery
Key to Fig. 49:
[1]
Outdoor unit (filled with refrigerant)
[2]
Indoor unit (filled with nitrogen)
[3]
Set of printed documents for product documentation
[4]
Fixing materials (5-8 screws and wall plugs)
[5]
Drainage elbow with gasket (for outdoor unit with floor or wall
mounting bracket) (may be attached to the outdoor unit upon
delivery)
[6]
Mounting plate
[7]
Remote control
[8]
5-core communication cable (optional accessory)
[9]
Remote control batteries (2)
[10] Remote control holder and fixing screw
[11] Magnetic ring
[12] Cold catalyst filter (black) and bio filter (green)
2.6
Product dimensions and minimum clearances
2.6.1
Indoor unit and outdoor unit
Figures 50 to 52.
2.6.2
Refrigerant lines
Key to figure 53:
[1]
Gas-side pipe
[2]
Liquid-side pipe
[3]
Siphon-shaped elbow as oil separator
If the outdoor unit is installed higher than the indoor unit, a siphon-
shaped elbow must be installed on the gas side. The installation must be
done at intervals of no more than 6 meters, and every 6 metres
thereafter ( Figure 53, [1]).
▶ Observe maximum pipe length and maximum difference in height
between indoor unit and outdoor unit.
2.7
Information on refrigerant
This device contains fluorinated greenhouse gases as refrigerant. The
unit is hermetically sealed. The following information on the refrigerant
complies with the requirements of EU Regulation No. 517/2014 on
fluorinated greenhouse gases.
Outdoor Unit Rated cooling
output
[kW]
CL7000i 20 E
2.0
CL7000i 26 E
2.5
CL7000i 35 E
3.4
CL7000i 41 E
4.0
CL7000i 53 E
5.0
Table 63 F-Gas
Climate 7000i – 6721873506 (2024/05)
Rated heating
Refrigerant
output
Type
[kW]
3.5
R32
4.1
R32
4.1
R32
4.6
R32
5.5
R32
Outdoor Unit
CL7000i 20 E
CL7000i 26 E
CL7000i 35 E
CL7000i 41 E
CL7000i 53 E
1) Gas side or liquid side
2) Measured from lower edge to lower edge.
Table 59 Pipe length and difference in height
Outdoor Unit
CL7000i 20 E
CL7000i 26 E
CL7000i 35 E
CL7000i 41 E
CL7000i 53 E
Table 60 Pipe diameter depending on unit type
Pipe diameter [mm]
6.35 (1/4")
9.53 (3/8")
12.7 (1/2")
Table 61 Alternative pipe diameter
Specification of the pipes
Min. piping length
Additional refrigerant to be added if the
pipe length exceeds 5 m (liquid side)
Piping Thickness
Thickness of insulation against heat
Material of insulation against heat
Table 62
Information for the installer: If you refill refrigerant, enter the additional
charge size and the total charge size of the refrigerant in the table
"information on refrigerant" below.
Global
CO
2
Warming
equivalent of
Potential
initial charge
(GWP)
[metric tons]
[kgCo
eq.]
2
675
0.57
675
0.61
675
0.61
675
0.68
675
0.84
Maximum pipe
Maximum difference
1)
length
[m]
≤ 25
≤ 25
≤ 25
≤ 25
≤ 30
Pipe diameter
Liquid side [mm]
6.35 (1/4")
6.35 (1/4")
6.35 (1/4")
6.35 (1/4")
6.35 (1/4")
Alternative pipe diameter [mm]
6
10
12
3 m
With Ø 6.35 mm (1/4"):
12 g/m
≥ 0.8 mm
≥ 6 mm
Polyethylene foam
Initial charge
Additional fill
volume [kg]
volume [kg]
0.85
(Pipe length-5)
*0.012
0.90
(Pipe length-5)
*0.012
0.90
(Pipe length-5)
*0.012
1.00
(Pipe length-5)
*0.012
1.25
(Pipe length-5)
*0.012
Product Information
2)
in height
[m]
≤ 10
≤ 10
≤ 10
≤ 10
≤ 20
Gas side [mm]
9.53 (3/8")
9.53 (3/8")
9.53 (3/8")
12.7 (1/2")
12.7 (1/2")
Total charge
volume during
commissioning
[kg]
67
