4.1.4
Functional test
The system can be tested once the installation including tightness test
has been carried out and the electrical connection has been established:
▶ Connect the power supply.
▶ Switch on indoor unit with the remote control.
▶ Press the
key to set the cooling mode (
▶ Press arrow key (/) until the lowest temperature is set.
▶ Test cooling mode for 5 minutes.
▶ Press the
key to set the heating mode (
▶ Press arrow key (.) until the highest temperature is set.
▶ Test heating mode for 5 minutes.
▶ Ensure freedom of movement of horizontal louvre.
You cannot use the remote controller to turn on the COOL function when
the ambient temperature is below 16°C. For that, use the MANUAL
CONTROL button to test the COOL function:
▶ Lift the front panel of the indoor unit, and raise it until it clicks in
place.
▶ The MANUAL CONTROL button is located on the right-hand side of
the display box. Press it once to manually start in AUTO mode. Press
it twice to activate the FORCED COOLING function.
▶ Perform the test run.
To switch on the cooling mode manually:
▶ Switch off the indoor unit.
▶ Press the key for the manual cooling mode twice with a thin object
( Fig. 70).
▶ Press the
key on the remote control to exit cooling mode when it
has been set manually.
In a system with multi-split air conditioner, manual operation is not
possible.
1
Outdoor unit and indoor unit are correctly installed.
2
Pipes are correctly
• connected,
• thermally insulated,
• and checked for tightness.
3
Condensate pipes are functioning correctly and
have been tested.
4
Electrical connection has been correctly
established.
• Power supply is in the normal range
• Protective conductor is properly attached
• Connection cable is securely attached to the
terminal strip
5
All covers are fitted and secured.
6
The horizontal louvre of the indoor unit is fitted
correctly and the actuator is engaged.
Table 68 Checklist
Climate 7000i – 6721873506 (2024/05)
4.2
▶ When the system has been set up, hand over the installation manual
▶ Explain to the customer how to use the system, referring to the
▶ Advise the customer to carefully read the operation manual.
).
).
Handover to the user
to the customer.
operation manual.
Commissioning
