Tekniske data
Grunnmaskin CNC SA/VA:
Rør – sveiseområde Ø (mm) ........................... 90-250 ....... 90-355 .......... 200-500 ....... 315-630
Rør - sveiseeffekt ............................................. SDR-rekker se sveising tabeller heftet + notat maks.
Maks. sylinderløft (mm) ................................... 150 ............ 150 ............... 200 .............. 200
Total – sylinderoverflate (cm²) ......................... 6,26 ........... 6,26 .............. 14,13 ........... 14,13
Hovedmål:
Lengde (mm) ............................................. 810 ............ 795 ............... 1300 ............ 1300
Bredde (mm) ............................................. 485 ............ 600 ............... 900 .............. 1060
Høyde (mm)............................................... 415 ............ 535 ............... 800 .............. 920
max. Vekt * (SA kg) ......................................... 59,0 ........... 80,2 .............. 238,5 ........... 323,4
max. Vekt * (VA kg) ......................................... 61,3 ........... 83,8
* inkl. reduksjons-spenninnsats for den minste rørdiameter
Freseinnretning:
Elektrisk tilkobling ............................................ 230 V .........230 V ............ 400 V, 3~ ..... 400 V, 3~
Opptatt -/ Avgitt effekt (W) ............................... 750/470 .....1050/650 ...... 1210/750 ...... 1770/110
-1
Motorturtall (min
) ............................................ 660 .............726 ............... 140 ............... 140
Tomgangsturtall Freseskive (min
Lydtrykknivå dB(A) L
pA
Lydeffektnivå dB(A) L
Vekt (kg) .......................................................... 15 ...............22,4 .............. 68 ................. 123
Varmeelement CNC SA/VA:
Elektrisk tilkobling ............................................ 230 V .........230 V ............ 400 V ............ 400 V
Varmeelement - diameter (mm) ....................... 300 .............380 ................ 540 ............... 660
Vekt (SA/VA kg) ............................................... 5,5/13 .........9,1 ................. 32 ................. 49
Innstillingsboks CNC SA/VA:
Vekt (SA/VA kg) ............................................... 8,2/7,6 .......9,6 ................. 55 ................. 70
Hydraulikaggregat:
Elektrisk tilkobling ............................................230 V – 50 Hz - 4,17 A .....400 V - 50/60 Hz - 2,75 A
Opptatt -/ Avgitt effekt (W) ...............................880/550 ............................1905/1100
Pumpematevolum (l/min) .................................2,2/ 2,6 .............................4,5/ 5,4
Olje – tankinnhold (l) ........................................1,1 ....................................3,8
maks. trykk (bar) ..............................................135 ...................................135
Hydraulikk - olje ...............................................HLP – 46 (no.: 53649)
Mål (LxBxH, mm) .............................................540 x 310 x 433 ................540 x 310 x 433
Lydtrykknivå dB(A) L
pA
Lydeffektnivå dB(A) L
Vekt (kg) ..........................................................33,7 ..................................38,2
Totalanlegg:
Elektrisk Total sluttverdi (kW) ..........................3,2 ..............4,3 ................ 7,2 ................ 11,7
198
-1
) ................. 85 ...............66 ................. 31 ................. 24
¦ K
............................. 82 ¦ 3 ..........83 ¦ 3 ............ 48 ¦ 3 ............ 52 ¦ 3
pA
¦ K
.......................... 93 ¦ 3 ..........94 ¦ 3 ............ 59 ¦ 3 ............ 63 ¦ 3
WA
WA
¦ K
.............................62 ¦ 3 ................................68 ¦ 3
pA
¦ K
..........................73 ¦ 3 ................................79 ¦ 3
WA
WA
P250B
P355B
Trykk hydraulikaggregat
50/60 Hz
50/60 Hz
3,5 A
4,8 A
50/60 Hz
50/60 Hz
1500 W
2500 W
P250B, P355B
230 V – 60 Hz - 4,17 A
P250B
P355B
NORSK
P500B
P630B
50/60 Hz
50/60 Hz
1,75 A
2,55 A
50/60 Hz
50/60 Hz
4000 W
8000 W
P500B, P630B
P500B
P630B
