CAUTION! Do not touch the trimmed, ready to weld surfaces. Ensure that the surfaces
are free of any and all containments and foreign objects!
Welding process in premium mode:
Risk of injury! Keep a safe distance from the machine when mechanically closing
clamps and moving workpieces. Keep hands, limbs and objects such as clothing, tools
etc. away from running machine!
Insert the heating element between the two work pieces in the basic machine, and make
sure that the heating plate supports are seated in the notches of the removal device.
Close the machine. The equalization pressure is automatically set. Hold the pressure.
Now all welding parameters have been stored, and the log activated.
If the welding process is interrupted using EXIT the message "Termination by the operator" ap-
pears, the pressure is dissipated and the welding parameters are stored. Confirm the message
with OK, then the program jumps to the main menu.
Release the pressure using the Automatic button (1) as soon as the required bulge height
has been reached evenly around the whole circumference of both pipes. The warming up
time t1 begins to run.
Set the pressure so that the ends of the work pieces can again be lain uniformly and nearly
pressure-free onto the heating element.
A signal sounds shortly before the end of the warm-up time.
After the warm-up time is over, separate the work pieces, remove the heating element and
bring the work pieces back together.
The form shows the temperature of the heating plate.
The display bar shows up in blue if the temperature is too low, and in
red when it is too high. When it is in the target range, it displays as
green.
The upper progress bar shows whether the pressure lies within the
correct range (green) or within a permissible (yellow) tolerance range
or whether it lies outside (red) the tolerance range. The actual pres-
sure is shown on the display (2).
