Transport case dimensions:
Length (mm) ....................................................1200 ...........1200 ............. 2240 ............. 2240
Width (mm) ......................................................800 .............800 ............... 1300 ............. 1300
Height (mm) .....................................................900 .............900 ............... 1500 ............. 1500
The noise level during operation can exceed 85 dB (A). Wear hearing protection!
3
Function of the Unit
3.1
Description
ROWELD P250-630B Premium CNC are compact, transportable heating element butt welding
machines with a CNC module for exact control, maintenance and storing according to DVS
guidelines. They also allow log files to be transferred through a USB connection specially de-
signed for use on construction sites, and particularly in pipe trenches. Of course, the tools are
very well suited for use in the workshop.
Welding of pipe-pipe connections, T-joints, pipe bends and welding neck can be made.
The essential machine components are:
Basic unit, reduction clamp insets, hydraulic unit with CNC module, trimmer unit, heating plate,
carrying frame.
ROWELD P250B Premium CNC: When welding pipe bends with a narrow radius of the maxi-
mum diameter of the machine, this bevelled upper clamping tool should be used as an accesso-
ry.
ROWELD P500-630B Premium CNC: To insert and remove the trimmer and the heating plate
we recommend using the electrical hoist (optional accessory, must be ordered separately).
3.1.1
Basic unit
1
Movable clamps
2
Sliding clamps
3.1.2
Hydraulic unit
1
Automatic button
2
Pressure button
3
Pressure release button
4
Adjusting knob
5
Cutting button
6
ON/OFF button
7
Heating button
8
"Open" machine
9
Temperature and time display
10
Release button
11
"Close" machine
The hydraulic unit allows the operator to operate the welding machine and perform the functions
indicated by the following symbols:
Turning the hydraulic assembly on and off
Press the „Heating" button to turn the heating element on. Set the desired heating
element temperature by pressing the „Heating" button and turning the adjustment
knob. The value will be shown in the temperature display, and then the current value is
again shown
Use the adjustment knob to set the pressure for cutting, aligning, heating and joining.
The value is shown in the „Pressure" display. Three seconds after the settings are
made, the current value is shown. Pressing the rotary knob displays and allows
changes to be made to the service parameters
30
3
Spacer with locking notch
4
Heating element take-off device
12
Timer button
13
Socket for cutting unit
14
Quick coupling for pipe collar
15
Quick coupling for plug
16
Heating element connector
17
Electrical plug
18
Emergency OFF
19
Touch screen PC
20
Oil filling port with dipstick
21
USB connection
22
Basic machine plug and socket device
ENGLISH
