Technical Data
Basic unit CNC SA/VA:
Pipe welding range Ø (mm) ............................. 90-250 ....... 90-355 .......... 200-500 ....... 315-630
Pipe capacity ................................................... SDR series see welding tables + observe pressure
Cylinder stroke, max. (mm) .............................. 150 ............ 150 ............... 200 .............. 200
Total cylinder surface (cm²) ............................. 6,26 ........... 6,26 .............. 14,13 ........... 14,13
Leading dimensions:
Length (mm) .............................................. 810 ............ 795 ............... 1300 ............ 1300
Width (mm) ................................................ 485 ............ 600 ............... 900 .............. 1060
Height (mm) ............................................... 415 ............ 535 ............... 800 .............. 920
max. Weight * (SA kg) ..................................... 59,0 ........... 80,2 .............. 238,5 ........... 323,4
max. Weight * (VA kg) ..................................... 61,3 ........... 83,8
* incl. reduction clamp inserts for the smallest pipe diameter
Trimmer unit:
Power supply ................................................... 230 V .........230 V ............ 400 V, 3~ ..... 400 V, 3~
Rated power input/output (W) .......................... 750/470 .....1050/650 ...... 1210/750 ...... 1770/110
-1
Rotary speed (min
) ........................................ 660 .............726 ............... 140 ............... 140
Idle running speed milling disc (min
Noise pressure level dB(A) L
Sound power level dB(A) L
Weight (kg) ...................................................... 15 ...............22,4 .............. 68 ................. 123
Heating plate CNC SA/VA:
Power supply ................................................... 230 V .........230 V ............ 400 V ............ 400 V
Heating plate - diameter (mm) ......................... 300 .............380 ................ 540 ............... 660
Weight (SA/VA kg) ........................................... 5,5/13 .........9,1 ................. 32 ................. 49
Carrying frame CNC SA/VA:
Weight (SA/VA kg) ........................................... 8,2/7,6 .......9,6 ................. 55 ................. 70
Hydraulic unit:
Power supply ...................................................230 V – 50 Hz - 4,17 A .....400 V - 50/60 Hz - 2,75 A
Rated power input/output (W) ..........................880/550 ............................1905/1100
Pump capacity (l/min) ......................................2,2/ 2,6 .............................4,5/ 5,4
Oil tank capacity (l) ..........................................1,1 ....................................3,8
Pressure max. (bar) .........................................135 ...................................135
Hydraulic-oil .....................................................HLP – 46 (no.: 53649)
Dimensions (LxWxH, mm) ...............................540 x 310 x 433 ................540 x 310 x 433
Noise pressure level dB(A) L
Sound power level dB(A) L
Weight (kg) ......................................................33,7 ..................................38,2
Overall length:
Total connected load (kW) ...............................3,2 ..............4,3 ................ 7,2 ................ 11,7
P250B
max. hydraulic unit
50/60 Hz
3,5 A
-1
) ............. 85 ...............66 ................. 31 ................. 24
¦ K
................ 82 ¦ 3 ..........83 ¦ 3 ............ 48 ¦ 3 ............ 52 ¦ 3
pA
pA
¦ K
................. 93 ¦ 3 ..........94 ¦ 3 ............ 59 ¦ 3 ............ 63 ¦ 3
WA
WA
50/60 Hz
1500 W
P250B, P355B
230 V – 60 Hz - 4,17 A
¦ K
................62 ¦ 3 ................................68 ¦ 3
pA
pA
¦ K
.................73 ¦ 3 ................................79 ¦ 3
WA
WA
P250B
ENGLISH
P355B
P500B
50/60 Hz
50/60 Hz
4,8 A
1,75 A
50/60 Hz
50/60 Hz
2500 W
4000 W
P500B, P630B
P355B
P500B
P630B
50/60 Hz
2,55 A
50/60 Hz
8000 W
P630B
29
