Clamping elements move together automatically. The cutting pressure can be increased
with the rotary knob (4). Standard cutting pressure is up to 20 bar, but it can be raised to
50 bar, see point 3.5.
An excessively high milling pressure can lead to overheating and damage to the miller
drive. When the milling drive is overloaded or at rest, raise the machine and reduce the
pressure (s. 3.5)!
After the shavings with a chip thickness of < = 0.2mm are discharged continuously from the
milling cutter, press on text field. Milling unit is switched off and the clamping elements start
up.
Wait until the cutting disks have stopped. Remove the cutting unit from the basic machine
and put it in the storage case.
Press text field, the work pieces move together and the drag flow pressure is measured.
The measured drag pressure will automatically be added to the equalization, warm-up and cut-
ting pressure.
Stay a safe distance away from the machine. Do not stand or reach into the machine.
Keep other people away from the work area!
Check, whether the pipes are resting firmly in the clamping elements, whether the welding
areas are plane, parallel and axially aligned.
Should the joint surfaces show any misalignment, repeat the trimming procedure. For best re-
sults the workpiece ends should not be mismatched by more than 10% of the wall thickness and
the maximum gap between the joint surfaces no more than:
Ø ≤ 355mm = 0,5mm, Ø 400...< 630mm = 1,0mm, Ø 630...< 800mm = 1,3mm.
This recommendation does not release you from your obligation to observe national welding
guidelines. Clear away any remaining shavings with a clean brush.
40
The arrow keys take the program back to „Please insert the trim-
mer..."
EXIT takes the program to the main menu without saving
The arrow keys take the program back to "Drag pressure finding"
The arrow keys take the program back to "Please insert the trimmer..."
EXIT takes the program to the main menu without saving
ENGLISH
