Use the adjusting knob (4) to select the desired parameter P001 to P009. If this value must
be adjusted or displayed, briefly press the adjusting knob (4). The (default) value blinks in
the lower display (9).
Use the adjusting knob (4) to set the value, and press the adjusting knob (4) briefly again.
Then the parameter blinks again in the upper display (2).
To leave the menu, press the release button (10). The values are stored.
How to set parameters with „master" rights:
Press the adjusting knob (4) for an extended time (about 6 sec.). First the parameter P001
blinks in the upper display (2). Then „CodE", and the line blinks in the first place in the lower
display (9).
Then use the adjusting knob (4) to enter the code, and briefly press the adjusting knob (4)
(code = 8001 – during first use the code can be changed as desired through parameter
P100).
Use the adjusting knob (4) to select the desired parameter, P101 to P114. If this value must
be adjusted or displayed, briefly press the adjusting knob (4). The (default) value blinks in
the lower display (9).
Use the adjusting knob (4) to set the value, and press the adjusting knob (4) briefly again.
Then the parameter blinks again in the upper display (2).
To leave the menu, press the release button (10). The values are stored.
Parameter
Description
name
P001
Remaining energy saver time
P002*
Power saving function active
P003
Heating plate temperature offset
P004
Pmax for cutting
P005
Target pressure
P006
Target temperature
P007
Timer T1 target value
P008
Timer T4 target value
P009
Pstart for cutting
P101
Deviation for repumping
P102
Lifting time after cutting
P103
Set temperature (min)
P104
Set temperature (max)
P105
Button lock (yes/no)
P106
Lifting pressure
P107
Full runtime until buzzer goes on
P100
Change code
* P002 - Power saving function:
0 - none,
1 - when the miller is running the heating element will be switched off, (Factory setting)
2 - when the hydraulic motor is running the heating element will be switched off,
3 - when t4 is running the heating element will be switched off.
44
default Unit
99
min
0
5
°C
20
bar
1/10bar
210
°C
45
sek
6
min
10
bar
5
%
10
1/10sek 0
160
°C
270
°C
5
sek
135
50
1/10sek 0
8001
ENGLISH
min
max
Rights
0
99
Welder
0
3
Welder
-25
25
Welder
10
50
Welder
Welder
P103 P104 Welder
1
1500 Welder
1
99
Welder
0
P004 Welder
1
50
Master
100
Master
0
300
Master
0
300
Master
0
50
Master
10
160
Master
200
Master
Master
