5.1 Dimensions, weights and connections
Fig. 14 | Dimensions
Aluminium: dimensions and weights
Size
RABO-CT G10 – G40
RABO-CF G10 – G40
RABO G16 – G65
RABO G100
RABO G160
RABO G250
RABO G400 DN 100
RABO G400 DN 150
Table 7 | Aluminium dimensions
Spheroidal cast iron: dimensions and weights
Size
G16 – G65
G65 (EBL 150**)
G100
G160
G250
Table 8 | Spheroidal cast-iron dimensions
* When connecting thermowells, pressure taps or the high-frequency pulse generator and when mounting a
volume conversion device, height C changes accordingly (example: RABO with fitted EK280 = B + 270 mm).
** EBL = Installation length
30
Dimensions [mm]
A
B
C*
121
126
160
171
126
160
171
192
216
171
192
216
241
256
280
241
256
280
241
256
280
241
280
315
Dimensions [mm]
A
B
C*
171
209
233
150
209
233
171
209
233
241
266
290
241
266
290
73021678h
© Elster GmbH | All rights reserved. Subject to modification
D
E
F
46
167
213
46
167
213
96
191
286
138
233
371
131
271
402
156
296
451
190
320
510
190
320
510
D
E
F
96
191
286
138
233
371
138
233
371
131
271
402
156
296
451
Weight
[kg]
5
6,5
11
15
30
34
41
40
Weight
[kg]
30
36
37
67
75
