Guaranteed sound power level
L
in dB(A)
WA
Volume of chain oil tank
Saw chain oiling
Stopping the device
Pull the cold start lever (choke)
Always work with both
hands!
Blade bar type
Adjusting the chain lub-
rication
Mixing ratio fuel to 2-
stroke oil: 40:1, ONLY
use fuel mixture
Press the petrol pump
six times
Fuel to be used
2-stroke oil to be used
Graphical symbol on sprocket
cover
Direction of travel of
saw chain
Chain brake (open/
closed)
Graphical symbol on chain brake
lever
Chain brake (activated/
deactivated)
Graphical symbol on blade bar
Blade bar type
Groove width
Chain pitch
Number of driving elements
Symbol on the hangtag
Activate the chain brake
Press the fuel pump
Pull the cold start lever (choke)
Pull the starter cord
3-4x
Operate the throttle lock and
throttle lever
Deactivate the chain brake
Safety instructions for
petrol chainsaws
Attention! Read the following safety
information to prevent personal injury
and damage to property.
General Information
• This appliance must not be used
by persons (including children) with
reduced physical, sensory or men-
tal capabilities, or lack of experi-
ence and knowledge.
Children must be supervised to en-
sure that they do not play with the
appliance.
• Pay attention to noise protec-
tion and local regulations when
working in the forest with chain-
saws. Local regulations may re-
quire a suitability test. Check with
the forestry administration.
• Do not use the chainsaw when
you are tired or ill or after taking
alcohol, tablets or drugs. Always
have a break on time.
