2. Fit the blade bar (10) and saw
chain (9) as described under
Installing the saw chain and blade
bar, p. 53.
Installing the saw chain and blade
bar
CAUTION! Always carry out main-
tenance and adjustment work with
the engine switched off and the spark
plug connector (32) disconnected.
CAUTION! Cutting injuries! Wear
cut-resistant gloves when working
with the saw chain or with the blade
bar.
Notes
• Before fitting a new saw chain:
Check the blade bar and chain
sprocket for damage.
Tools and aids required
• Combination tool
Procedure (Fig. A)
1. Place the device on a level sur-
face.
2. Deactivate the chain brake: Pull
the chain brake lever (12) back to-
wards the front handle (1).
You can only refit the sprocket
cover (13) when the chain brake
band has been released.
3. Place the blade bar (10) on the
blade bar bolts (23) and slide it
onto the chain sprocket (24).
4. Thread the saw chain (9) over the
chain sprocket (24).
5. Place the saw chain (9) on the top
of the blade bar (10) in the blade
bar groove. Start at the chain
sprocket (24). It is normal for the
saw chain (9) to sag.
6. Pull the blade bar (10) forwards to
tension the saw chain (9).
7. Put the sprocket cover (13) back in
position. Ensure that the chain ten-
sioner pin (28) engages in the re-
ceptacle (25).
8. Tighten the two nuts (15) on the
sprocket cover (13) hand-tight.
The blade bar should still be able
to move.
9. Tension the saw chain: Turn the
chain tensioner screw (14) with the
combination tool (17) ⭮ .
10. Tighten the nuts (15) of the
sprocket cover (13) using the com-
bination tool (17).
Tensioning the saw chain
NOTICE! Do not re-tension or change
the saw chain when it is hot because
it shrinks slightly once it has cooled
down. If this is not observed it can
lead to damage on the guide rail or
the engine because the saw chain is
now too taut on the blade bar.
Regularly tightening the saw chain
provides safety for the user and re-
duces and/or prevents wear and
chain damage. We recommend that
the user check the chain tension be-
fore starting work and at intervals of
approx. 10 minutes and correct it if
necessary. The saw chain warms up
when working with the saw and thus
expands slightly. These "expansions"
can be expected especially from new-
er saw chains.
Chain tension and chain lubrication
have a significant impact on the ser-
vice life of the saw chain. The chain
tension of a new saw chain must be
readjusted after a maximum of 5 cuts.
The saw chain is properly tensioned
when it does not hang from the un-
derside of the blade bar and cannot
be moved around by a gloved hand.
When pulling on the saw chain with
9 N (approx. 1 kg) of force, the saw
chain and blade bar should not be
separated by a distance of more than
2 mm.
