● Fit protective cap (W), lower spacing
ring (V), blade disc (I), upper spacing
ring (U), deflector (T) and retaining
washer (P) onto the blade mounting
and insert screw (O).
● Use installation tool (X) to counterhold
the blade disc. Screw in screw (O)
using combination spanner (Z) and
tighten to a torque of 52 - 60 Nm.
7.6 Removing the blade disc
● Use installation tool (X) to
counterhold the blade disc.
● Loosen screw (O) with combination
spanner (Z).
● Remove screw (O), retaining
washer (P), deflector (T), upper
spacing ring (U) and blade disc (I).
7.7 Installing the feed chute
The closure screws (Q) must be
securely fastened to the feed chute
following initial assembly.
● Insert closure screws (Q) in the slot of
the feed chute and screw in fully,
applying pressure.
● Attach feed chute (A) to hinge (1) in
basic unit and pivot forwards.
● Tighten both closure screws (Q)
simultaneously.
7.8 Removing the feed chute
● Loosen both closure screws (Q)
until they turn freely. They remain
on the feed chute
38
● Pivot feed chute (A) to the rear and
remove.
7.9 Fuel and engine oil
Top up engine oil before initial start
( engine instruction manual)!
Engine oil
Please consult the engine instruction
manual for the type of engine oil to be used
and the oil capacity. Check the oil filling
9
level at regular intervals ( see engine
instruction manual). Avoid exceeding or
falling below the correct oil level.
Fuel
Recommendation:
Fresh good quality fuel, normal unleaded
petrol ( engine instruction manual)! Use
a funnel when filling the tank with fuel (not
included in standard equipment). Note the
warnings in the section "For your safety".
10
( 4.)
8. Notes on working with the
machine
Risk of injury:
Observe the safety instructions in
the "For your safety" section. ( 4.)
It is only permitted for one person to
feed the garden shredder.
11
8.1 Working area for operator
● For safety reasons, the operator
must stay within the working area
(grey area X) for the entire operating
12
period (while the motor is switched on
or the engine is running), particularly in
order to prevent injuries due to
shredding material that is ejected
backwards.
To feed shredding material, stand slightly
to the side of the feed chute.
Risk of injury!
The inclined blade unit can cause
hard material to kick back. Hard
material kickback may result in
serious injury to the user. To avoid
injury from kickback, never stand
directly behind the feed chute.
8.2 What material can be processed?
Tree or hedge cuttings as well
as branch material with
numerous or few twigs and
side shoots can be processed
with the garden shredder.
Tree and hedge cuttings should be
processed when fresh, as the
shredding performance is better
with fresh than with dried-out or wet
shredding material.
Processing dry shredding material
increases the risk of kickback.
Branch kickback may result in
severe injury to the user.
13
0478 216 9908 B - EN
