The technical documents are stored at
STIHL Tirol GmbH.
The year of manufacture and machine
number are indicated on the garden
shredder.
Langkampfen, 01.07.2022
STIHL Tirol GmbH
p.p.
Matthias Fleischer, Vice President Product
Development
p.p.
Sven Zimmermann, Head of Quality
Division
17. Technical specifications
Manufacturer's
STIHL
brand:
Model:
GH 370.1 S
Serial number:
6001
Engine, design:
4-stroke com-
bustion engine
0478 216 9908 B - EN
Type:
EVC 1000.0
Nominal output at
3,4 | 3000
nominal speed:
kW | rpm
Displacement:
196 cc
Starter:
Rope start
Fuel tank:
1,4 l
Cutting unit drive:
Permanent
Measurement in accordance with
2000/14/EC / S.I. 2001/1701:
Guaranteed sound
power level L
103 dB(A)
WAd
Uncertainty K
3,0 dB(A)
WA
Measurement in accordance with EN
13683:
Sound pressure level
at workplace L
94 dB(A)
pA
Uncertainty K
3 dB(A)
pA
Torque,
blade set:
52 – 60 Nm
Torque,
reversible blade:
22 – 28 Nm
L/W/H:
128/77/140 cm
Weight:
45 kg
17.1 REACH
REACH is an EC Regulation for the
registration, evaluation, authorisation and
restriction of chemicals.
Information on compliance with the
REACH Regulation (EC) No. 1907/2006 is
available from www.stihl.com/reach.
18. Troubleshooting
@ See engine instruction manual.
 If necessary, contact a specialist
dealer; STIHL recommends STIHL
specialist dealers.
Fault:
Engine not starting
Possible cause:
– Feed chute not properly closed
– Blocked blade disc
– No fuel in tank; blocked fuel line
– Inferior, dirty or old fuel in tank
– Spark plug socket detached from spark
plug; ignition lead not properly fastened
to socket
– Dirty air filter
– Dirty or damaged spark plug; incorrect
electrode gap
– Engine flooded due to several starting
attempts
Remedy:
– Close feed chute properly and tighten
screws ( 7.7)
– Remove shredder deposits from
housing (important: first detach spark
plug socket)
– Top up fuel; clean fuel line ( 7.9)
– Always use fresh, good quality fuel,
normal unleaded petrol; clean
carburettor ( 7.9)
– Connect spark plug socket; check
connection between ignition lead and
socket 
– Clean air filter 
– Clean or replace spark plug; adjust
electrode gap 
– Remove spark plug and dry; pull recoil
starter rope repeatedly with spark plug
removed (switch in O position)
45
