7. Lift and hold the delivery hose
press the On / Off switch
(8)
v If the pump does not deliver water after approx. 5 minutes,
switch off the pump (press On / Off switch
(see 6. TROUBLESHOOTING).
The specified maximum self-priming suction height of 7 m is reached
only if the pump is filled via the filler neck
doing so and during the self-priming, the delivery hose
ficiently high to prevent any water escaping from the pump via the delivery
hose
(5)
.
Rust formation: The pump Art. 9014 has a cast iron housing. After con-
tact with water, rust will form (this does not damage the pump and is not
covered by the warranty). Therefore rusting water may initially escape after
switching on the pump.
4. MAINTENANCE
DANGER! Risk of injury!
Injury when the product starts accidentally.
v Disconnect the product from the mains before you maintain
the product.
To flush the pump:
After pumping chlorinated water, the pump must be flushed.
1. Pump lukewarm water (max. 35 °C), possibly adding a mild cleaning
agent (e. g. detergent) until the pumped water runs clear.
2. Remove residuals according to the waste disposal laws applicable in
your area.
5. STORAGE
To put into storage [ Fig. S1 ]:
The pump is not frost-proof!
The product must be stored away from children.
1. Disconnect the pump from the mains.
2. If applicable, close all the shut-off devices on the intake side.
3. Open all the tapping points.
The pressure side is depressurized.
4. Open the screw fitting
(6)
of the filler neck
(9)
screw
.
The Garden Pump drains.
5. Store the pump in a dry, enclosed and frost-free place.
6. TROUBLESHOOTING
DANGER! Risk of injury!
Injury when the product starts accidentally.
v Disconnect the product from the mains before you trouble-
shoot the product.
To loosen the impeller [ Fig. T1 ]:
An impeller blocked by dirt can be freed again.
v Turn shaft of the impeller
(10)
This will loosen the stuck impeller.
Problem
Possible Cause
Pump is running, but the
Leaky or damaged suction
suction action doesn't take
hose.
place
The pump was not filled with
water.
The liquid escapes over the
hose which is connected to
the delivery side during the
suction action.
Absolutely vacuumresistant connection is achieved by using
GARDENA Suction Hoses (see 8. ACCESSORIES).
GAR_09010-20.960.04_2025-03-10.indd 9
GAR_09010-20.960.04_2025-03-10.indd 9
(5)
at least 1 m vertically above the pump,
and wait until the pump has primed.
(8)
)
(7)
up to the overflow and if, while
(5)
is held up suf-
(7)
and the water drain
with a screwdriver.
Remedy
v Check suction line for
damage and seal so is
airtight.
v Fill the pump
(see 3. OPERATION).
v 1. Fill the pump again
(see 3. OPERATION).
2. When starting operation
hold the pressure hose
approx. 1 m vertically
above the pump, until the
suction action has taken
place.
Problem
Possible Cause
Pump is running, but the
Leaky screw fitting at the filler
suction action doesn't take
neck.
place
Air cannot escape, since
delivery side is closed or
remaining water is in the
pressure hose.
The waiting time wasn't
observed.
Suction filter or backflow
preventer in the suction hose
clogged.
Too high suction height.
In case of any other difficulties concerning the suction action,
use GARDENA Suction Hoses with Backflow Preventer
(see 8. ACCESSORIES) and fill in the liquid to be pumped
over the filler neck before operation.
Pump does not start,
Thermal switch has turned
or stops suddenly during
the pump off because of over
operation
heating.
No power supply to the pump.
RCD has triggered
(residual current).
Pump is not switched on.
Pump is running but the
Suction hose end is not
delivery drops suddenly
in water.
Suction filter or backflow
preventer clogged.
Leaks at suction side.
Impeller blocked.
Noise development in the
In the case of strong flows (e.g. open hose end, without connec
hydraulic area
ting device), noise may result in the hydraulic part of the pump.
This is harmless and does not lead to damage of the pump.
The noise can be removed by lightly changing the flow (e. g. light
opening / closing of a connecting device).
NOTE: For any other malfunctions please contact the GARDENA service
department. Repairs must only be done by GARDENA service departments
or specialist dealers approved by GARDENA.
7. TECHNICAL DATA
Garden Pump
Unit
Value
(Art. 9010)
Rated power
W
600
Mains voltage
V (AC)
230
Mains frequency
Hz
50
Max. delivery capacity
l/h
3000
Max. pressure /
bar /
3.5 /
max. delivery head
m
35
Max. self-priming suction
m
7
height
Permitted internal pressure
bar
6
(delivery side)
Power cable
m
1.5 (H07RNF)
Weight
kg
5.3
Sound power level L
1)
WA
measured / guaranteed
dB(A)
77 / 80
Max. media temperature
°C
35
Measuring process complying with:
RL 2000/14/EU
1)
8. ACCESSORIES / SPARE PARTS
GARDENA Suction Hoses
Kinkproof and vacuumproof, optionally available by the metre
Art. 1720 / 1721 (19 mm (3/4") / 25 mm (1")) without connecting
fittings or in fixed length Art. 9090 / 9091 complete with connecting
fittings.
Remedy
v Check seal (replace if neces
sary) and tighten connection
securely (do not use pliers).
v Open shutoff valves
(e g. nozzle) in the delivery
line, empty the delivery hose
or disconnect it from the
pump during priming.
v Switch on the pump and wait
up to 5 min.
v Clean the filter or the back
flow preventer.
v Reduce suction height.
v Observe the max. media
temperature (35 °C).
v Check fuses and electrical
plug connections.
v Disconnect the pump
and contact the GARDENA
Service.
v Push the On / Off switch
to On.
v Submerge the end of the suc
tion hose deeper in the water.
v Clean the suction filter or
backflow preventer.
v Eliminate leak.
v Release impeller.
Value
Value
(Art. 9014)
(Art. 9015)
800
800
230
230
50
50
3700
3700
4.1 /
4.1 /
41
41
7
7
6
6
1.5 (H07RNF)
1.5 (H07RNF)
8.2
6.1
77 / 80
75 / 78
35
35
9
