Systeem 2.2 4
Sensoren
Relais; pWM / 0-10 V
collector 1
S1
2WK collector 1
boiler 1 onder
S2
2WK collector 2
boiler 2 onder
S4
zonnepomp
collector 2
S6
3WK boiler 2
S1 S6
R1
R4
R2
R3; A
S2
30
R1
R2
R3; A
R4
S4
Systeem 2.2 5
Sensoren
Relais; pWM / 0-10 V
collector 1
S1
2WK collector 1
boiler 1 onder
S2
2WK collector 2
boiler 2 onder
S4
zonnepomp
collector 2
S6
2WK boiler 1
2WK boiler 2
S1 S6
R1
R2
R3; A
S2
R4
R5
R1
R2
R3; A
R4
R5
S4
