Systeem 3.2 1
R3
Sensoren
Relais; pWM / 0-10 V
collector 1
S1
pomp collector 1
boiler 1 onder
S2
pomp collector 2
boiler 2 onder
S4
3WK boiler 2
collector 2
S6
pomp collector 3
collector 3
S8
S1
S6 S8
R1; A
R4; C
R2; B
R3
S2
R1; A
R2; B
R3
R4; C
S4
Systeem 3.2 2
Sensoren
Relais; pWM / 0-10 V
collector 1
S1
pomp collector 1
boiler 1 onder
S2
pomp collector 2
boiler 2 onder
S4
2WK boiler 1
collector 2
S6
2WK boiler 2
collector 3
S8
pomp collector 3
S1
S6 S8
R5; C
R1; A
R2; B
S2
R3
R4
R1; A
R2; B
R3
R4
R5; C
S4
37
