Systeem 3.4 3
Sensoren
Relais; pWM / 0-10 V
collector 1
S1
zonnepomp boiler 1
boiler 1 onder
S2
zonnepomp boiler 2
boiler 2 onder
S4
zonnepomp boiler 3
boiler 3 onder
S5
zonnepomp boiler 4
collector 2
S6
2WK collector 1
boiler 4 onder
S7
2WK collector 2
collector 3
S8
2WK collector 3
S1
S6 S8
R5
R6
R7
S2
R1; A
R2; B
R1; A
R2; B
R3; C
R4; D
R5
R6
R7
S4
S5
S7
R3; C
R4; D
Systeem 3.4 4
Sensoren
Relais; pWM / 0-10 V
collector 1
S1
2WK collector 1
boiler 1 onder
S2
2WK collector 2
boiler 2 onder
S4
zonnepomp
boiler 3 onder
S5
2WK boiler 1
collector 2
S6
2WK boiler 2
boiler 4 onder
S7
2WK boiler 3
collector 3
S8
2WK boiler 4
2WK collector 3
S1
S6 S8
R1
R2
R8
R3; A
S2
R4
R5
R1
R2
R3; A
R4
R5
R6
R7
R8
S4
S5
S7
R6
R7
43
