Systeem 3.2 5
Sensoren
Relais; pWM / 0-10 V
collector 1
S1
2WK collector 1
boiler 1 onder
S2
2WK collector 2
boiler 2 onder
S4
zonnepomp
collector 2
S6
2WK boiler 1
collector 3
S8
2WK boiler 1
2WK boiler 3
S1
S6 S8
R6
R1
R2
S2
R4
R5
R1
R2
R3; A
R4
R5
R6
S4
Systeem 3.3 1
Sensoren
Relais; pWM / 0-10 V
collector 1
S1
pomp collector 1
boiler 1 onder
S2
pomp collector 2
boiler 2 onder
S4
2WK boiler 1
boiler 3 onder
S5
2WK boiler 2
collector 2
S6
2WK boiler 3
collector 3
S8
pomp collector 3
S1
S6 S8
R2; B
R6; C
R1; A
S2
R3
R4
R1; A
R2; B
R3
R4
R5
R6; C
S4
S5
R5
