Systeem 2.3 5
Sensoren
Relais; pWM / 0-10 V
collector 1
S1
2WK collector 1
boiler 1 onder
S2
2WK collector 2
boiler 2 onder
S4
zonnepomp
boiler 3 onder
S5
3WK boiler 1
collector 2
S6
3WK boiler 2
S1
S6
R1
R2
R5
R4
R3; A
S2
S4
R1
R2
R3; A
R4
R5
S5
Systeem 2.4 1
Sensoren
Relais; pWM / 0-10 V
collector 1
S1
pomp collector 1
boiler 1 onder
S2
pomp collector 2
boiler 2 onder
S4
2WK boiler 1
boiler 3 onder
S5
2WK boiler 2
collector 2
S6
2WK boiler 3
boiler 4 onder
S7
2WK boiler 4
S1
S6
R1; A
R2; B
S2
S4
R3
R4
R5
R1; A
R2; B
R3
R4
R5
R6
S5
S7
R6
33
