Systeem 2.3 1
Sensoren
Relais; pWM / 0-10 V
collector 1
S1
pomp collector 1
boiler 1 onder
S2
pomp collector 2
boiler 2 onder
S4
2WK boiler 1
boiler 3 onder
S5
2WK boiler 2
collector 2
S6
2WK boiler 3
S1
S6
R1; A
R2; B
S2
S4
R3
R4
R5
R1; A
R2; B
R3
R4
R5
S5
Systeem 2.3 2
Sensoren
Relais; pWM / 0-10 V
collector 1
S1
zonnepomp boiler 1
boiler 1 onder
S2
zonnepomp boiler 2
boiler 2 onder
S4
zonnepomp boiler 3
boiler 3 onder
S5
2WK collector 1
collector 2
S6
2WK collector 2
S1
S6
R4
R5
S2
S4
R1; A
R2; B
R3; C
R1; A
R2; B
R3; C
R4
R5
S5
