Systeem 2.4 2
Sensoren
Relais; pWM / 0-10 V
collector 1
S1
pomp collector 1
boiler 1 onder
S2
pomp collector 2
boiler 2 onder
S4
3WK boiler 1
boiler 3 onder
S5
3WK boiler 2
collector 2
S6
3WK boiler 3
boiler 4 onder
S7
S1
S6
R1; A
R2; B
R4
R3
S2
S4
34
R1; A
R2; B
R3
R4
R5
R5
S5
S7
Systeem 2.4 3
Sensoren
Relais; pWM / 0-10 V
collector 1
S1
zonnepomp boiler 1
boiler 1 onder
S2
zonnepomp boiler 2
boiler 2 onder
S4
zonnepomp boiler 3
boiler 3 onder
S5
zonnepomp boiler 4
collector 2
S6
2WK collector 1
boiler 4 onder
S7
2WK collector 2
S1
S6
R5
R6
S2
S4
R1; A
R2; B
R3; C
R1; A
R2; B
R3; C
R4; D
R5
R6
S5
S7
R4; D
