Systeem 2.4 4
Sensoren
Relais; pWM / 0-10 V
collector 1
S1
2WK collector 1
boiler 1 onder
S2
2WK collector 2
boiler 2 onder
S4
zonnepomp
boiler 3 onder
S5
2WK boiler 1
collector 2
S6
2WK boiler 2
boiler 4 onder
S7
2WK boiler 3
2WK boiler 4
S1
S6
R1
R2
R3; A
S2
S4
R4
R5
R6
R1
R2
R3; A
R4
R5
R6
R7
S5
S7
R7
Systeem 2.4 5
Sensoren
Relais; pWM / 0-10 V
collector 1
S1
2WK collector 1
boiler 1 onder
S2
2WK collector 2
boiler 2 onder
S4
zonnepomp
boiler 3 onder
S5
3WK boiler 1
collector 2
S6
3WK boiler 2
boiler 4 onder
S7
3WK boiler 3
S1
S6
R1
R2
R5
R6
R4
R3; A
S2
S4
R1
R2
R3; A
R4
R5
R6
S5
S7
