Systeem 3.4 1
Sensoren
Relais; pWM / 0-10 V
collector 1
S1
pomp collector 1
boiler 1 onder
S2
pomp collector 2
boiler 2 onder
S4
2WK boiler 1
boiler 3 onder
S5
2WK boiler 2
collector 2
S6
2WK boiler 3
boiler 4 onder
S7
2WK boiler 4
collector 3
S8
pomp collector 3
S1
S6 S8
R2; B
R1; A
R7; C
S2
R3
R4
42
R1; A
R2; B
R3
R4
R5
R6
R7; C
S4
S5
S7
R5
R6
Systeem 3.4 2
Sensoren
Relais; pWM / 0-10 V
collector 1
S1
pomp collector 1
boiler 1 onder
S2
pomp collector 2
boiler 2 onder
S4
3WK boiler 1
boiler 3 onder
S5
3WK boiler 2
collector 2
S6
3WK boiler 3
boiler 4 onder
S7
pomp collector 3
collector 3
S8
S1
S6 S8
R1; A
R6; C
R2; B
R3
R4
S2
R1; A
R2; B
R3
R4
R5
R6; C
R5
S4
S5
S7
