MX2 Cane Clamp Installation
A
H E L P F U L H I N T
Spray a small amount of hairspray
on the back canes and on the
inside of the plastic inserts to create
a secure 'no-slip' bond.
3
Starting on one side, slide/adjust the Cane Clamp assembly (B) to the
desired height/position along the back cane and tighten secure it in place.
Note: The final back height may be further adjusted/fine tuned following
installation of the MX2 back shell onto the cane clamps (see Fig. 5)
MX2 Cane Clamp Height Adjustment
Fig. 5
B
- F F
M
IXED
B
REAR VIEW
(Wheelchair with back removed)
Install Cane Clamps at the same
height and parallel to each other
I
OUNT
NSTALLATION
B
1
3
2
A
Fig. 4
B
