6.0 MX2 O
6.1 (Optional) Lumbar Support Installation/Adjustment
!
P L E A S E N O T E
The Lumbar Support is a pre-fabricated foam insert that provides
lower back support for additional comfort. The position of the lumbar
insert can be adjusted inside the Invacare
instructions below), or it may be removed if no lumbar support is
desired.
1.To access the lumbar support, open the hook and loop fastening strips on
the outer cover A at the bottom rear of the back shell.
2.The foam lumbar support B is installed inside the Invacare
cover between the foam back cushion C and the back shell D.
3.The lumbar support can be adjusted to any desired height/position.
4.Refasten the cover (via hook and loop strips) onto the back pan.
Lumbar Support
FRONT
All manuals and user guides at all-guides.com
PTIONS
®
®
Matrx
MX2 cover (see
®
Matrx
*NOTE: The lumbar foam may
be cut/modified as needed, to
meet the needs of the end user.
adjust lumbar position as
needed or remove completely
®
MX2
