3.0 MX2 B
ACK
IMPORTANT! Unless otherwise required, all depth, height and angle
adjustments are to be made symmetrically on the left & right mounting plates.
MX2 Fixed Mount: DEPTH Adjustment
Fig. 7a
-1.5"
(38mm)
1
Rearmost
Installation
MX2 Fixed Mount: WIDTH/HEIGHT Adjustment
Fig. 8a
1
All manuals and user guides at all-guides.com
- F F
M
IXED
+1.5"
(38mm)
Width Adjustment:
1⅛" (29 mm)
per side
I
OUNT
NSTALLATION
Forwardmost
1
Installation
Fig. 7b
2
1/2"
(13 mm)
(relative to Cane Clamp)
Height Adjustment*
2
Front
