3.0 MX2 B
ACK
3.1 Fixed Mounting Hardware Kit
i) Mounting Bracket Assembly (installs onto Mx2 Back Shell):
2 - Fixed Mounting Brackets (A)
2 - Fixed Bracket Nut Plates (B)
ii) Cane Clamp Assembly (installs onto Wheelchair Back Canes):
2 - Cane Clamp (E)
2 - Cane Inserts 7/8" (22 mm) (F)
2 - Cane Inserts 3/4" (19 mm) (G)
(Right Hardware Assembly Shown)
D
H
J
- F F
M
IXED
OUNT
2 - Fixed Bracket Washer Plates (C)
4 - Fixed Bracket Screws (D)
4 - Depth/Recline Adjustment Screws (H)
2 - Cane Clamp Screws (J)
2 - Cane Clamp Nut Plates (K)
C
E
(19
I
NSTALLATION
K
A
G
F
7/8"
3/4"
(22
)
)
mm
mm
B
