Figure 10 - Place the underside of the battery on
the lower battery holder.
2. Place the underside of the battery k at an angle onto the lower battery holder z.
3. Carefully tilt the battery k against the upper battery holder h.
4. Press the lock j on the top of the battery.
Figure 12 - Press the lock and push the battery
into the top holder.
5. Push the battery in the top holder until it locks and the key turns upright.
6. Close the battery cover.
78
Figure 11 - Tilt the battery against the top
battery holder.
Figure 13 - Close the battery cover.
