A
Figure 17 - Inserting the charging plug into the battery.
3. Open the battery holder cap v (only when charging in the e-bike).
4.
Insert the charging plug of the charger l into the battery k
(Figure 17B).
The power unit of the e-bike does not operate while the battery is being charged in the
4
battery holder.
Once the battery is fully charged, all battery level LEDs b and the on-board computer will turn
off.
5. Disconnect the charger l from the battery k.
6. Disconnect the charger l from the power supply.
7. Close the cap of the battery holder v (only when charging in the e-bike).
If you do not disconnect the charger after charging, the charger will automatically turn on
4
again after several hours, check the battery level and begin charging again if necessary.
4.6. Installing and removing the on-board computer
Figure 18 - Installing the on-board computer.
1. Install the on-board computer 4 with the top in the holder on the handlebars.
B
(Figure 17A) or battery holder
Figure 19 - Clicking the on-board computer into
place.
EN
81
